The Rotary Vane Principle

Our rotary vane compressors are an embodiment of our dedication to our reputation as manufacturers of quality and reliable products. Each rotary vane unit provides up to 100,000+ operating hours thanks to their simple, low-speed direct drive design which results in low noise, low stresses and a long working life.

Benefits of Vane Technology

• Small and compact
• High quality clean dry air
• No gears or belt
• Low noise levels
• Pro electronic controller (4kW)
• Tripod or receiver mounted

Designed for You... Built to Last
In addition to a very long lifespan, these compressors can deliver clean, dry and pulse free, quality air straight from the outlet – requiring less downstream equipment. Operating at low speeds (1,450 - 1,760 rpm) results in low noise, low stresses and a long service life.

Options available:

• Tripod or Receiver mounted:
• 50 / 60 Hz
• 1.1 to 7.5 kW
• 7 to 10 bar
• 0.21 to 1.27 m³/min (4.2 to 44.7 cfm)

Reliable air supply, day after day
The open, fixed speed CMPV01 - CMPV04 models are small and compact and with noise levels as low as 62 dB(A), are ideally suited to light industrial and workshop applications where the compressed air outlet needs to be situated close to the point of use.

Designed and built with the highest levels of efficiency and energy savings in mind, our engineers have developed rotary vane compressors for the twenty first century, whilst retaining features that have helped build Broomwade’s reputation for quality and reliability around the world.
